This resource consists of rendering exercises and activities. No
preparation needed other than to print at the desired paper size. This
teaching resource has been developed for students studying Technical
drawing, Graphics lessons or Technology Mandatory classes. It consists
of a range of drawings which can be provided to students at a variety of
levels at the teachers discretion.
The resource includes
engineering objects that provide opportunities for students to extend
their knowledge and skills in Orthogonal drawing practice.
Some drawings will require some teacher instruction and guidance prior to students attempting the drawings.
Many of the drawings can be used as cover lessons when the usual teacher is not available for the class.
Sheets included in this resource are listed below.
1. Glossary of terms
2. Practice 1
3. Cylinders and cones
4. Cube 1
5. Cube 2
6. Brick and stone work
7. C Clamp
8. Sliding block
9. Engine mount
10. Pipe support
11. Shaft bracket
13. VW Beetle
14. Rendering a car
15. House 1
16. House 2
17. House 3
